North American XB-21

XB-21

Role: Medium bomber
National origin: United States
Manufacturer: North American
First flight: December 22, 1936
Primary user: United States Army Air Corps
Number built: One
Unit cost: $122,000 USD

The North American XB-21, also known by the manufacturer's model designation NA-21, and sometimes referred to by the name "Dragon", was a prototype bomber aircraft developed by North American Aviation in the late 1930s, for evaluation by the United States Army Air Corps. Evaluated against the Douglas B-18 Bolo, it was found to be considerably more expensive than the rival aircraft, and despite the ordering of a small number of evaluation aircraft, only the prototype was ever built.

Design and development

North American Aviation's first twin-engined military aircraft, the NA-21 prototype was constructed at North American's factory in Inglewood, California, where work on the aircraft began in early 1936. The NA-21 was a mid-wing monoplane of all-metal construction, powered by two Pratt & Whitney R-2180 Twin Hornet radial engines, which were fitted with turbosuperchargers for increased high-altitude performance.

Flown by a crew of six to eight men, the XB-21 featured a remarkably strong defensive armament for the time, including as many as five .30-calibre M1919 machine guns. These were planned to be fitted in hydraulically powered nose and dorsal turrets, in addition to manually operated weapons installed in waist and ventral positions. Up to 10,000 pounds (4,500 kg) of bombs could be carried in an internal bomb bay, with 2,200 pounds (1,000 kg) of bombs being able to be carried over a range of 1,900 miles (3,100 km).

Testing and evaluation

Undertaking its maiden flight on December 22 1936 at Mines Field, company test flying indicated a number of minor problems. Modifications resolving these resulted in the aircraft being re-designated NA-39, and, accepted by the U.S. Army Air Corps as the XB-21. The aircraft, which had been assigned the serial number 38-485, was evaluated early the following year in competition against a similar design by Douglas Aircraft, an improved version of the company's successful B-18 Bolo. During the course of the fly-off, the gun turrets proved troublesome, their drive motors proving to be underpowered, and issues with wind blast through the gun slots were also encountered. As a result of these problems, the XB-21's nose turret was faired over, while the dorsal turret was removed.

The XB-21 proved to have superior performance over its competitor, but price became the primary factor distinguishing the Bolo and the XB-21. On this account, the modified B-18 was declared the winner of the competition, Douglas quoting a price per aircraft of $64,000 USD, while North American's estimate was $122,000 USD per aircraft, and an order was placed for 177 of the Douglas aircraft, to be designated B-18A. Despite this, the Army Air Corps found the performance of the XB-21 to have been favorable enough to order five pre-production aircraft, to be designated YB-21. However, soon after this contract was awarded, it was cancelled, and none of the YB-21s were ever built, leaving the XB-21 as the sole example of the type ever constructed. Operated by North American Aviation, the XB-21 served as a research aircraft until its retirement.

Legacy

Although the XB-21 failed to win a production contract, it was the first of a long line of North American Aviation medium bomber aircraft, and provided experience and knowledge that assisted in the development of the North American NA-40, which, developed into the B-25 Mitchell, would become one of the Army's standard medium bombers of the Second World War.

Specifications (XB-21)

Picture - The XB-21 prototype undergoing maintenance

Data from

General characteristics

Crew: Six to eight
Length: 61 ft 9 in (18.82 m)
Wingspan: 95 ft 0 in (28.96 m)
Height: 14 ft 9 in (4.50 m)
Wing area: 1,120 sq ft (104 m)
Empty weight: 19,082 lb (8,655 kg)
Gross weight: 27,253 lb (12,362 kg)
Max takeoff weight: 40,000 lb (18,144 kg)
Powerplant: 2 x— Pratt & Whitney R-2180 Twin Hornet turbosupercharged radial engines, 1,200 hp (890 kW) each
Propellers: 3-bladed

Performance

Maximum speed: 220 mph (350 km/h; 190 kn) at 10,000 feet (3,000 m)
Cruise speed: 190 mph (170 kn; 310 km/h)
Range: 1,960 mi (1,703 nmi; 3,154 km) with 2,200 pounds (1,000 kg) of bombs
Combat range: 600 mi (521 nmi; 966 km) with 10,000 pounds (4,500 kg) of bombs
Service ceiling: 25,000 ft (7,620 m)
Time to altitude: 10 minutes to 10,000 feet (3,000 m)

Armament

Guns: Five .30-calibre machine guns, mounted in single turrets in the nose and dorsal positions, and single manually operated mounts in the waist and ventral positions.
Bombs: Up to 10,000 pounds (4,500 kg) in an internal bay.

Comparable aircraft

Breguet 693
Bristol Blenheim
Douglas B-18 Bolo
Martin Model 146
PZL.37 �oś

Bibliography

Baugher, Joe. "North American XB-21". Accessed 2010-05-21.
Donald, David, ed. The Complete Encyclopedia of World Aircraft. London: Orbis, 1997. ISBN 0-7607-0592-5.
Jones, Lloyd S. U.S. Bombers, B1-B70. Fallbrook, CA: Aero Publishers, 1962. ASIN B0007FFBSO.
Reuter, Claus. Development of Aircraft Turrets in the AAF, 1917-1944. New York: S.R. Research & Publishing, 2000. ISBN 1-8946-4308-9.
Rusinek, Ed. "A Tale of Two Dragons". North American Aviation Retirees Bulletin, Winter 2005.
Yenne, Bill. The Story of the Boeing Company. St. Paul, MN: Zenith Press, 2005. ISBN 0-7603-2333-X.
Yenne, Bill. The American Aircraft Factory in World War II. St. Paul, MN: Zenith Press, 2006. ISBN 0-7603-2300-3.
