Yokosuka Ro-go Ko-gata

Role: Reconnaissance floatplane
National origin: Japan
Manufacturer: Yokosuka
Introduction: 1918
Primary user: Imperial Japanese Navy
Number built: 218

The Yokosuka Ro-go Ko-gata was a Japanese reconnaissance floatplane developed during the First World War by the Japanese Navy Arsenal at Yokosuka, and one of the first indigenous Japanese aircraft to enter production. 218 aircraft were built for the Imperial Japanese Navy, remaining in use until 1928.

Development and design

The Japanese Navy Arsenal at Yokosuka became involved in aircraft production in 1913, when an aeroplane factory was set up, with its first work being to build several Maurice Farman and Curtiss Seaplanes. It continued to build aircraft under license, including more Farman aircraft and several Short 184 seaplanes, as well as prototypes of several of its own designs.

In 1917, Chikuhei Nakajima, chief designer of the Yokosuka Arsenal aircraft factory designed a new reconnaissance floatplane, with a prototype of the new design, powered by a 140 hp (104 kW) Salmson water-cooled radial engine, making its maiden flight early in 1918. Test results were good, and the type was ordered into production as the Ro-go Ko-gata.

The Ro-go Ko-gata was a three-bay biplane of wood and fabric construction, with twin main floats and wings that folded backwards for storage. Its crew of two sat in separate, closely spaced cockpits. Initial production aircraft were powered by 200 hp (149 kW) Salmson engines, but the majority of production aircraft were fitted with 200-220 hp (149-164 kW) Mitsubishi-built Hispano-Suiza 8 V-8 engines.

A total of 218 aircraft were built in total, 32 by the Yokosuka arsenal, 80 by Aichi and 106 by the Nakajima Aircraft Company, with production continuing until 1924. It was the first locally designed aircraft to be built in large numbers for the Japanese Navy.

Operational history

Three of the early aircraft were modified in 1919 for making long-range flights, with one of the cockpits being replaced by more fuel, allowing a record flight of 1,300 km (808 mi) to be flown in 11 hours 35 min on 20 April 1919. The Ro-go Ko-gata, along with licenced built Hansa-Brandenburg W.29s, replaced the obsolete pusher Farmans in Japanese Navy service, remaining in large scale service until 1926, being re-designated Yokosho-Type Reconnaissance Seaplane in 1923. Several were sold for civilian use, being used to carry air-mail, being operated until 1928.

Units using this aircraft

Japan

Imperial Japanese Navy

Specifications (Production type)

Data from Japanese Aircraft 1914-1941

General characteristics

Crew: 2
Length: 10.16 m (33 ft 4 in)
Wingspan: 15.692 m (51 ft 5.8 in)
Height: 3.666 m (12 ft 0.3 in)
Wing area: 48.22 m (519.0 sq ft)
Empty weight: 1,070 kg (2,359 lb)
Gross weight: 1,628 kg (3,589 lb)
Powerplant: 1 x— Mitsubishi type Hi water cooled V8 engine, 160 kW (220 hp)
Propellers: 2-bladed

Performance

Maximum speed: 156 km/h; 97 mph (84 kn)
Range: 778 km; 483 mi (420 nmi)
Endurance: 5 hr
Time to altitude: 4 min to 500 m (1,640 ft)

Armament

Guns: 1x— flexibly mounted 7.7 mm machine gun

Under the designation system introduced by the Imperial Japanese Navy in 1918, this designation corresponded to Model A reconnaissance aircraft.
Yokosho was an acronym standing for Yokosuka Kaigun Ko-Sho (Yokosuka Naval Arsenal).

Donald, David (ed.) The Encyclopedia of World Aircraft. Leicester, UK: Blitz Editions, 1997. ISBN 1-85605-375-X.
Mikesh, Robert and Abe, Shorzoe. Japanese Aircraft 1910-1941. London:Putnam, 1990. ISBN 0 85177 840 2.
